NITYA G3

Stupeň krytí (IP66) Degree of protection
Zjistit více ikonka Learn more about the product
Zjistit více ikonka Learn more about the product
NITYA G3

Electrical parameters

Light source LED
Power voltage AC 220-240 V / 50-60 Hz
Connection method protection class II – leading out cable 30 cm
Ballast part electronic driver with surge protection L/N-Ground 10 kV
Surge protection additional surge protection 20 kA (1,5 kV)
Possibility of regulation non-dimmable (not labeled), DALI (DALI)
  preparation for wireless communication NEMA (N) » Zhaga (Z)
  - only for NITYA L and NITYA XL
Emergency module NO

Light parameters

Optical system (P51), (P52), (T54), (L19), (C51), (C52), (C56)
Light distribution direct
Colour rendering index Ra > 70
Colour temperature AMBER (BLUE FREE) » 2 200 k » 2 700 K » 3 000 K » 4 000 K
Service life > 100,000 hrs. (L90B10)

Construction

Luminaire body aluminum cast
Colour RAL 9022
Surface type mat
Luminaire cover safety glass

Safety

Protection class II
Maximum ambient temperature MAX. -40 / +50 °C
Ingress protection IP 66
Impact protection IK 09
Mounting on normally flammable surfaces YES

Mounting

Method by mounting on a caliper (part of the luminaire), tilt 0–90°
Recommended height from 6 to 15 m

Accessories

Clips NO
Use open areas, parking, public areas, sports facilities
