EMERGENCY MODULE

A separate emergency module with the option to attach it to industrial luminaires of the Elektro-Lumen brand.

Stupeň krytí (IP65) Degree of protection
Zjistit více ikonka Learn more about the product
Zjistit více ikonka Learn more about the product
EMERGENCY MODULE

Electrical parameters

Light source LED
Power voltage DC 230 V (central battery)
Connection method terminal block
Autonomy period the autonomy of 1 hrs. (1)
Safe Mode permanently lit (M), lit in case of failure (NM)
Emergency module  manual test (without marking) » auto test (AT) » central battery (CB)

Light parameters

Optical system corridor (CC), areal distribution (D)
Light distribution direct
Colour rendering index Ra > 70
Colour temperature 4,000 K
Service life > 100,000 hrs. (L80B20)

Construction

Luminaire body powder-coated steel sheet
Colour RAL 9003
Surface type gloss

Safety

Protection class I
Maximum ambient temperature +5 / +40 °C
Protection of the luminaire's electrical part IP 65
Protection of the luminaire's optical part IP 65
Mounting on normally flammable surfaces YES

Mounting

Method by attaching it to the light fixture (it is necessary to specify the type of light fixture)
by attaching (to order) » hanging (to order)
Recommended height max. up to 15 m

Accessories

Clips NO
Suspension accessories NO
Use industrial areas, logistics centers, warehouses
